The classification of the fully automatic filling machine

Mechanization popularization have taken the place of a lot of manual work content, fully automatic filling machine is a very typical example. Such device has simple structure, high production efficiency, variety, strong practicability, and is suitable for various industries.

Atmospheric pressure:

1. The liquid materials under atmospheric pressure condition, load the container, only used for filling of low viscosity, gas free materials, such as wine, vinegar, soy sauce, etc. From the tank into the bottle, the bottle, bottle feeding conveyor, filling valve, the main shaft and transmission system. In the same horizontal plane, into the wheel and the wheel, tray installed on the lifting lever, spindle vertical installed on the bearing seat, the top 1 is installed on the spindle, 24 refill valve under the tank. The middle section of 24 tray, lifting movement by the track. Motor and drive system device installed in the atmospheric pressure inside the frame of full automatic filling machine.

2. Negative pressure: the container form negative pressure pump, the liquid into the container. Negative pressure filling machine is divided into two kinds, (1) positive pressure storage tank, the negative pressure container, rely on differential pressure filling (differential pressure filling machine); (2), packaging container are all negative pressure storage tank, liquid filling the load (gravity type negative pressure filling machine). Scope of application: filling juice drinks, toxic pesticides, chemical reagents.

3. Pressure: with external mechanical stress, fluid filled in the container. Can fill the viscous material, the fluid. Such as toothpaste, tomato sauce, bean paste, balsam, etc. Seasoning made from stainless steel box 1. Welding boxes at the bottom of form, and at the bottom of shaft rigidity connection. At the bottom of the box body are 12 piston, piston rod bottom roller, roller along the circular orbit, control the reciprocating movement of the piston. Rail end is equipped with lifting gear, used to adjust the piston stroke.
